Right-Angle Double-Head Furniture Connector Pin — Bright metal connector pin shown with two perpendicular cylindrical legs and shaped capture heads at the outer ends. Final component geometry, panel and hole interfaces, mating parts, material, finish, quantity and packaging require confirmation.
Product Overview
| Photographed Configuration | Bright metal connector pin shown with two perpendicular cylindrical legs and shaped capture heads at the outer ends. |
|---|---|
| Purchasing Position | Furniture connector or support assembly requiring panel, hole, mating-component and installation confirmation. |
| Order Boundary | Photographed colors, dimensions and quantities do not define the production order. |
| Quotation Basis | Approved drawing or sample, mating part or panel, installation conditions, quantity, packaging and acceptance criteria. |
Specifications & Custom Capability
Current Product Configuration
| Product Type | Right-Angle Double-Head Furniture Connector Pin |
|---|---|
| Current Product Configuration | Bright metal connector pin shown with two perpendicular cylindrical legs and shaped capture heads at the outer ends. |
| Primary Form | Right-angle two-leg connector transferring between two concealed capture interfaces in adjoining furniture components. |
| Head / Interface | Confirm both head and neck profiles, leg diameters and lengths, bend geometry and radius, shoulders, clearances and installed projection. |
| Thread / Mating Part | No external thread is visible in the main photos; confirm each mating capture component and interface from drawing or sample. |
| Current Appearance | Bright metallic appearance shown; confirm base material, finish system and visible-surface acceptance. |
| Material | Confirm according to drawing, sample or purchase specification. |
| Installation | Confirm adjoining panel or component sections, hole or cavity locations, centerlines, insertion sequence and capture direction. |
| Dimensions & Tolerances | Confirm according to drawing, sample or purchase specification. |
Custom Manufacturing & Order Review
| Made-to-Drawing | Available for review with component drawings, panel-hole specification, joint section and mating-component details. |
|---|---|
| Made-to-Sample | Available for comparison with representative connectors, panels, mating parts and approved finish samples. |
| Component Geometry | Cam, pin, support body, sleeve, connector head, shank, shoulder and panel interfaces can be reviewed against the approved furniture joint. |
| Threaded Component Range | Threaded screws or dowels from M1 to M12 can be reviewed only where compatible with the confirmed furniture assembly, material, geometry and installation method. |
| Threaded Component Length | Threaded screws or dowels from 3 mm to 200 mm can be reviewed only where compatible with the confirmed panel, joint, engagement and manufacturing route. |
| Finish Options | Zinc plating, Ruspert coating, spray painting, electrophoretic coating, blackening, gold plating, silver plating and copper plating can be reviewed only where compatible with the confirmed base material, geometry, service environment and acceptance requirement. |
| Packaging & Private Label | Bulk, counted bags, compartment packs or private-label cartons can be reviewed after component identity, quantity, protection, labels and artwork are approved. |
| MOQ | 10,000 pcs per confirmed specification |
| Samples | Request a representative sample with the proposed components, panels, holes, finish and packaging specification. |
Applications
| Corner furniture joints | Coordinate both legs and capture interfaces with the approved joint section. |
|---|---|
| Cabinet frame connections | Confirm hole centerlines, projection and assembly access. |
| Replacement joint pins | Compare both heads, legs, bend and mating components. |
| OEM connector sets | Control matched mating parts, counts, labels and instructions. |
Buyer Guide
| Which dimensions define the bend? | Specify both leg axes and lengths, bend radius, shoulder positions and angular tolerance. |
|---|---|
| How are the end heads matched? | Provide both mating capture parts and required installed projection. |
| Can material be confirmed from the photo? | No. Confirm material and finish in the purchase specification. |
| What should an assembly trial include? | Use production-representative panels, holes, capture parts and installation sequence. |
Quality Control
| Heads and necks | Inspect both capture profiles, transitions and surface condition. |
|---|---|
| Legs and bend | Check diameters, lengths, angle, radius, straightness and finish. |
| Joint assembly trial | Verify insertion, projection, capture, pull-up and release by the specified method. |
| Set and pack audit | Confirm mating-part ratio, identity, instructions, count and protection. |
Packaging & Customization
| Packaging Format | Bulk, counted bags, compartment packs or private-label cartons can be reviewed after component identity, quantity, protection, labels and artwork are approved. |
|---|---|
| Identification | Use approved item codes, quantities, labels, barcodes and carton marks. |
| Component Protection | Prevent mixed parts, movement and visible-surface damage through the confirmed pack design. |
| Private Label | Submit approved artwork, language, barcode data and legal marking requirements before production. |
Frequently Asked Questions
| Is the order limited to the photographed furniture component? | No. The gallery records the current photographed configuration. Final component geometry, panel and hole interfaces, mating parts, material, finish, quantity and packaging require an approved drawing or sample. |
|---|---|
| Can the furniture connector or support geometry be customized? | Component geometry can be reviewed against the confirmed panel, hole layout, mating parts and installation method. M1 to M12 threads and 3 mm to 200 mm lengths apply only to compatible screw or dowel components after technical review. |
| Which dimensions define the bend? | Specify both leg axes and lengths, bend radius, shoulder positions and angular tolerance. |
| Which finishes can be reviewed for metallic components? | Zinc plating, Ruspert coating, spray painting, electrophoretic coating, blackening, gold plating, silver plating and copper plating can be reviewed only where compatible with the confirmed base material, geometry, service environment and acceptance requirement. |
| Can the package and label be customized? | Bulk, counted bags, compartment packs or private-label cartons can be reviewed after component identity, quantity, protection, labels and artwork are approved. |
| What is required for quotation? | Send the component and panel drawings or samples, hole specification, mating parts, installation method, material and finish requirement, quantity and packaging artwork. MOQ starts at 10,000 pcs per confirmed specification. |
Need a Custom Quote?
Send a drawing or sample and the confirmed assembly requirements. JH Fix will review manufacturing compatibility, sample scope and quotation details.
| RFQ 1 | Connector drawing or approved samples |
|---|---|
| RFQ 2 | Both capture heads and mating parts |
| RFQ 3 | Leg diameters, lengths, shoulders and bend |
| RFQ 4 | Panel or component holes and joint section |
| RFQ 5 | Material, finish and joint test method |
| RFQ 6 | Set quantity, labels, instructions and packaging |
MOQ: 10,000 pcs per confirmed specification
