Brass-Colored Hex-Socket Countersunk Machine Screw — Brass-colored machine screws shown with flat countersunk heads, internal hex drives, uniform full threads and blunt ends. Final thread, length, head, material, finish, mating part, quantity and packaging require confirmation.
Product Overview
| Photographed Configuration | Brass-colored machine screws shown with flat countersunk heads, internal hex drives, uniform full threads and blunt ends. |
|---|---|
| Purchasing Position | Custom machine-thread component requiring geometry, mating-thread and assembly confirmation. |
| Order Boundary | Photographed colors, dimensions and quantities do not define the production order. |
| Quotation Basis | Approved drawing or sample, mating part or panel, installation conditions, quantity, packaging and acceptance criteria. |
Specifications & Custom Capability
Current Product Configuration
| Product Type | Brass-Colored Hex-Socket Countersunk Machine Screw |
|---|---|
| Current Product Configuration | Brass-colored machine screws shown with flat countersunk heads, internal hex drives, uniform full threads and blunt ends. |
| Primary Form | Countersunk machine screw intended to seat in a prepared recess and engage a confirmed nut, insert or tapped hole. |
| Head / Interface | Confirm head diameter and angle, head height, hex drive size and depth, seating face, under-head transition and tool access. |
| Thread / Mating Part | Confirm machine-thread diameter, pitch and class, threaded length, end profile, mating thread and required engagement. |
| Current Appearance | Warm brass-colored finish is shown; confirm base material, coating or plating system, color range, corrosion requirement and approved sample. |
| Material | Confirm according to drawing, sample or purchase specification. |
| Installation | Confirm mating nut, insert or tapped hole, joint stack, countersink, clearance hole, driver, tightening method and buyer acceptance criteria. |
| Dimensions & Tolerances | Confirm according to drawing, sample or purchase specification. |
Custom Manufacturing & Order Review
| Made-to-Drawing | Available for review with screw or connector drawings, joint section and mating-part specification. |
|---|---|
| Made-to-Sample | Available for comparison with representative screws, connectors, mating parts and approved finish samples. |
| Custom Thread Range | Machine-thread components from M1 to M12 can be reviewed where compatible with the confirmed subtype, mating thread, head geometry and application. |
| Custom Length Range | Lengths from 3 mm to 200 mm can be reviewed where compatible with the confirmed diameter, head geometry, engagement, manufacturing route and purchase specification. |
| Finish Options | Zinc plating, Ruspert coating, spray painting, electrophoretic coating, blackening, gold plating, silver plating and copper plating can be reviewed only where compatible with the confirmed base material, geometry, service environment and acceptance requirement. |
| Packaging & Private Label | Bulk, counted bags, compartment packs or private-label cartons can be reviewed after part identity, quantity, protection, labels and artwork are approved. |
| MOQ | 10,000 pcs per confirmed specification |
| Samples | Request a representative sample made to the proposed geometry, thread, finish and packaging specification. |
Applications
| Flush furniture hardware | Coordinate countersink, joint stack and mating thread. |
|---|---|
| Cabinet mechanism assembly | Confirm driver access, seating and engagement. |
| Decorative metal fixtures | Approve visible color and surface with the mating hardware. |
| OEM machine-fastener packs | Control thread variants, count, labels and surface protection. |
Buyer Guide
| Which mating-thread data are required? | Provide nut, insert or tapped-hole thread, class, engagement and joint stack. |
|---|---|
| How is the countersunk head approved? | Match head diameter and angle to the prepared recess and finished surface requirement. |
| Does the color prove the coating process? | No. Confirm the finish process, color standard, corrosion requirement and approved sample. |
| Can the photographed size define production? | No. Confirm all dimensions and tolerances by drawing, sample or purchase specification. |
Quality Control
| Head and hex drive | Inspect head diameter and angle, recess geometry, seating face and burrs. |
|---|---|
| Machine thread | Check diameter, pitch, class, length, end and thread damage. |
| Mating assembly trial | Verify countersink seating, engagement, tool access and buyer-specified tightening test. |
| Finish and pack audit | Confirm color, surface, variant identity, count, labels and protection. |
Packaging & Customization
| Packaging Format | Bulk, counted bags, compartment packs or private-label cartons can be reviewed after part identity, quantity, protection, labels and artwork are approved. |
|---|---|
| Identification | Use approved item codes, quantities, labels, barcodes and carton marks. |
| Component Protection | Prevent mixed parts, movement and visible-surface damage through the confirmed pack design. |
| Private Label | Submit approved artwork, language, barcode data and legal marking requirements before production. |
Frequently Asked Questions
| Is the order limited to the photographed screw configuration? | No. The gallery records the current photographed configuration. Final geometry, thread, material, finish, quantity and packaging require an approved drawing, sample or purchase specification. |
|---|---|
| Can thread and length be customized? | Machine-thread components from M1 to M12 and lengths from 3 mm to 200 mm can be reviewed according to subtype, head geometry, mating thread, engagement, manufacturing route and purchase specification. |
| Which mating-thread data are required? | Provide nut, insert or tapped-hole thread, class, engagement and joint stack. |
| Which finishes can be reviewed? | Zinc plating, Ruspert coating, spray painting, electrophoretic coating, blackening, gold plating, silver plating and copper plating can be reviewed only where compatible with the confirmed base material, geometry, service environment and acceptance requirement. |
| Can the package and label be customized? | Bulk, counted bags, compartment packs or private-label cartons can be reviewed after part identity, quantity, protection, labels and artwork are approved. |
| What is required for quotation? | Send the screw or connector drawing or sample, mating part, joint stack, material and finish requirement, installation method, quantity and packaging artwork. MOQ starts at 10,000 pcs per confirmed specification. |
Need a Custom Quote?
Send a drawing or sample and the confirmed assembly requirements. JH Fix will review manufacturing compatibility, sample scope and quotation details.
| RFQ 1 | Screw drawing or approved sample |
|---|---|
| RFQ 2 | Head angle, hex drive, thread and tolerances |
| RFQ 3 | Mating nut, insert or tapped-hole specification |
| RFQ 4 | Joint stack, countersink and installation method |
| RFQ 5 | Material, finish, color and corrosion requirement |
| RFQ 6 | Quantity, labels and packaging |
MOQ: 10,000 pcs per confirmed specification
